- Multi Gas Detector KT-602
-
-
Multi Gas Detector
Product model：KT-602
Accurate acousto-optic alarm, large screen display, simple operation, with intelligent sensor. All these advantages centre on a small but solid gas detector KT-602 which is applied to multi gas detection.
As the most sensitive multi gas alarm detector in the present industrial circle, KT-602 responds quickly and accurately to the toxic gas, in order to alarm in time if the leakage or danger occurred.
Hostile operating environment is a stern challenge for the detector, such as broiling, severe cold, damp, dusty, etc. KT-602 was designed for exceedingly rugged surroundings, with explosion-proof and flame retardant crust, light and portable.
Inspection and alarm will be continuous even if the detector were dropped or crashed. It is the primary inspection tool with high performance-price ratio and multiple functions in the field of multiple gas detecting.
Features
1、Aseismatic design is applied to rugged surroundings;
2、Continuously gas concentration and composition LCD real-time display;
3、Rechargeable lithium battery (continuous working period can be 16~18 hours);
4、95 dB acoustic alarm and two wide-angle optic alarm;
5、Built-in vibration alarm which is applied for noisy environment;
6、Two stage alarm threshold: the low alarm point and high alarm is applicable to all gas;
7、Simple automatic calibration program and plug-in replaceable electrochemical sensor;
8、Fully functional self-testing: sensor, integrity of battery and circuit, acoustic & visual & vibration three-stage alarm.
9、Small figure and light weight
10、Common application includes mining, metallurgy, petroleum, chemical, power, telecommunication, urban construction, etc.
Functions
1、Real-time detection for the concentration of appointed gas.
2、Gas Alert Micro series have a wide application, including HAZMAT response, enclosure space entry and post fire inspection.
3、The deadline date and alarm threshold can be adjusted based on the request in special industry.
4、 Password protection capability: only the authorized user can modify the preset parameter.
Gas
Detecting Range
Alarm Threshold
Sensor Type
NH3
0-100 PPM
25 PPM / 50 PPM
Electrochemical sensor
Cl2
0-50.0 PPM
0.5 PPM / 1.0 PPM
H2
0-1000 PPM
50 PPM / 100 PPM
CH2O
0-100 PPM
25 PPM / 50 PPM
O2
0-30.0%vol
18.5%vol / 23.5%vol
H2S
0-100 PPM
10 PPM / 20 PPM
HCl
0-30.0 PPM
5.0 PPM / 10.0 PPM
HCN
0-50.0 PPM
5.0 PPM / 10.0 PPM
PH3
0-20.0 PPM
0.3 PPM / 0.6 PPM
HF
0-10.0 PPM
3.0 PPM / 6.0 PPM
NO
0-250 PPM
25 PPM / 50 PPM
CO
0-500 PPM
35 PPM / 70 PPM
SO2
0-20.0 PPM
2.0 PPM / 4.0 PPM
ClO2
0-50.0 PPM
0.3 PPM / 0.5 PPM
NO2
0-20.0 PPM
1.0 PPM / 2.0 PPM
C2H4O
0-100 PPM
1 PPM / 10 PPM
O3
0-20.0 PPM
5.0 PPM / 10.0 PPM
CH4
0-100%LEL
25%LEL / 50%LEL
Catalytic combustion sensor
C3H8
0-100%LEL
25%LEL / 50%LEL
H2
0-100%LEL
25%LEL / 50%LEL
NH3
0-100%LEL
25%LEL / 50%LEL
C2H4O
0-100%LEL
25%LEL / 50%LEL
CH3CH3
0-100%LEL
25%LEL / 50%LEL
C2H4
0-100%LEL
25%LEL / 50%LEL
C4H10
0-100%LEL
25%LEL / 50%LEL
C4H8
0-100%LEL
25%LEL / 50%LEL
C7H8
0-100%LEL
25%LEL / 50%LEL
C8H10
0-100%LEL
25%LEL / 50%LEL
CH4O
0-100%LEL
25%LEL / 50%LEL
C2H6O
0-100%LEL
25%LEL / 50%LEL
C2H3Cl
0-100%LEL
25%LEL / 50%LEL
C2H7N
0-100%LEL
25%LEL / 50%LEL
CH3Br
0-100%LEL
25%LEL / 50%LEL
Remark: Some gas types are not listed. If any query, please contact the manufacturer. The alarm threshold value can be adjusted based on customer’s request.
Operating & Storage Environment
Temperature: -20℃~55℃ (-4F~122F)
Humidity: 5%-95% (Relative humidity non-condensing)
Pressure: 95~110kPa
Alarm Threshold (Two-stage)
There may be regional variations, users can set up the value based on the practical situation.
Detecting Range
CO: 0~500 PPM
SO2:0~20 PPM
O2: 0~30.0%vol
Ex(CH4): 0~100%LEL
Other gas types: referring to the gas parameter list
Sensor
Referring to the gas parameter list
Alarm Type
low & high alarm, multiple gas alarm, sensor alarm, battery low alarm, prompt tone, automatic shutdown alarm
Acoustic Alarm
Variable-frequency pulse alarm which can reach volume of 95dB in a distance of 1 foot (0.3 meters)
Visual Alarm
Two red LBD omnibearing visible glitter alarm
Vibration Alarm
Pulsant signals alert the gas alarm or any other alarm status
Display
Alphanumeric large LCD displays the real time gas concentration and alarm stage
Backlight
Automatically activated when working in poor lighting environment or the alarm sounding or the button is knobbed down.
Self-checking Function
Self-checking after start up.
Calibration Function
Automatic zero point calibration ;
Automatic measurement range calibration.
Power Supply
Rechargeable lithium battery
Weight
211g
Dimensions
126mm*66mm*33mm
